- Reduced oil consumption and waste oil
- Can effectively extend oil life up to 40,000 hours delivering very significant reduction of oil consumption, waste, and disposal costs.
- Low operational cost increases the life of full flow filters
- Greatly improves machine productivity and reliability by longer life of all bearings, hydraulic actuators, valves, pumps, and all lubricated working components.
- IMPORTANT REDUCTION OF MAINTENANCE COST
Product Description
Multi-Element housings for low-pressure applications and/or low viscosity applications
FEATURES:
- Ideal for High flow filter rigs. Flow rates up to 60 l/m (6000 l/hour).
- SS Housing Series are compact built carbon steel housings for large volume systems and high flow requirements.
- Effectively removing all of the particles that are usually very difficult to remove with conventional filters, performing a total cleaning of the oil by removing solid particles, eliminating sludge, absorbing water and eliminating other oil oxidation residues.
- Can be combined with suction filters, first stage pre filters and centrifuges to build custom made solutions.
- They come in a range of sizes and accept a large range of Triple R (RRR) element options, making them suitable for many purposes.
- In combination with the X-series elements suitable for high viscosity oil up to 600 cSt.
- The housings have a strong lid and can handle pressure up to 15 bar system pressure.
TYPICAL APPLICATIONS
- Large Volume Systems
- Lube Systems and High Viscosity Systems
- For High Flow Filter Rigs
The SS Series has 12 different housings to suit your filtration needs, these are:
Multi-Element Housing – 100 Size Depth Filters:
Multi Element housing for low-pressure applications – M series elements fitted.
- SS102-H114 | TR-11400
- SS103-H114 | TR-11410
- SS104-H80 | TR-POA
Multi-Element Housing – 300 Size Depth Filters:
Multi element housings for low-pressure applications – M series elements fitted.
- SS305-H114 | TR-10515
- SS306-H80 | TR-10520
- SS315-H114 | TR-10535
- SS321-H114 | TR-10545
- SS327-H114 | TR-POA
Multi Element Housing – Cartridge
Multi Element housings for low pressure, low viscosity applications. Elements sold separately
- SS-4PF20 | TR-11460
- SS-6PF20 | TR-11620
- SS-12PF20 | TR-12660
Suction Filter (Suction Screen)
- SS Suction LL | Tr-15817
*DP – Design pressure of flow control (Nominal flow rate ± 10% guaranteed between these pressures.
LEARN ALL ABOUT TRIPLE R BYPASS OIL CLEANER
